T4112502042-000 4 Position Circular Connector Plug Female Sockets Screw

Lead Time:1-2 Weeks
MOQ:1PCS
Product Type:Circular Metric Connectors
Connector Type:Plug, Female Sockets
Shell Size - Insert:M12-4
Mounting Type:Free Hanging (In-Line), Right Angle
Termination:Screw
Fastening Type:Threaded
Contact Finish - Mating:Silver

SEND INQUIRY

You can make an inquiry about this product.
Your e-mail will not be leaked.

PRODUCT DETAIL

T4112502042-000 Circular Metric Connectors M12,FEMALE,RA,D CODE ,4P,PG9,SILVER

Product Type:Circular Metric Connectors

Connector Type:Plug, Female Sockets

Number of Positions:4

Shell Size - Insert:M12-4

Mounting Type:Free Hanging (In-Line), Right Angle

Termination:Screw

Fastening Type:Threaded

Orientation:D

Primary Material:Metal

Shell Material:Brass

Shell Finish:Nickel

Contact Finish - Mating:Silver

Color:Black, Silver

Ingress Protection:IP67 - Dust Tight, Waterproof

Features:Backshell, Coupling Nut

Shielding:Unshielded

Current Rating (Amps):4A

Voltage Rating:250V

Operating Temperature:-40°C ~ 85°C

Backshell Material, Plating:Polybutylene Terephthalate (PBT), Glass Filled

Contact Material:Bronze

Contact Finish Thickness - Mating:80.0µin (2.03µm)

Insert Material:Polyamide (PA), Nylon

Subcategory:Circular Connectors

INGKE also produce substitute such as:

T4112401042-000 T4112501042-000 T4112002042-000 T4140412041-000 T4142412041-000 T4112402042-000 T4112502042-000 T4110501041-000 T4143512041-000 T4143412041-000 T4111001052-000 T4111401052-000...
